ViewZ VZ-C10X10MAI-4W C-Mount Motorized Zoom Auto-Iris 2/3” Cameras

Retail: $690

ViewZ VZ-C10X10MAI-4W C-Mount Japan Motorized Zoom Auto-Iris 2/3” Cameras

Description:

Explore the versatility of the ViewZ VZ-C10X10MAI-4W, a high-performance motorized zoom lens perfect for 2/3”, 1/2”, and 1/3” cameras. Built in Japan, this lens offers advanced features designed to meet professional imaging needs with precision and reliability.

Key Features:

• Focal Length: 10-100mm with 10x Zoom Ratio for dynamic range.
• Maximum Aperture: F1.4 for exceptional light capture.
• Auto-Iris Functionality: Ensures optimal exposure with built-in EE Amplifier.
• Compatibility: Designed for 2/3”, 1/2”, and 1/3” cameras.
• Angular Field of View: 47.5° x 36.5° at 10mm to 5.0° x 3.8° at 100mm.
• Precision Build: C-Mount adjustable lens position with front thread (62 mm P0.75).
• Durable Construction: Operates in temperatures from -10°C to 50°C (14°F to 122°F).
• Compact Size: Measures 80mm (W) x 70mm (H) x 122.3mm (D), weighing approximately 700g.

Specifications:

• Operation Modes:

  • Zoom: Motorized (DC +/- 6.4V, max 40mA, speed approx. 6 seconds).
  • Focus: Motorized (DC +/- 6.4V, max 40mA, speed approx. 7 seconds).
  • Iris: Motorized (DC +8.5 to 16V, fixed voltage, max 60mA).

• Input Signal: Composite or Video Signal, sensitivity adjustable 0.5 ~ 1.0 Vp-p.

• Object Dimensions at M.O.D.: 105.6 x 79.1cm at 10mm and 10.6 x 8.0cm at 100mm.

Additional Details:

This lens includes features such as flange back adjustment, tripod fixing compatibility (1/4-20UNC screw), and built-in EE Amp for precise iris control. It's ideal for professional imaging in a range of environments.
